| Spin Riveting Machine |
|
|
| Orbital bench spin riveting machine is precision engineered to ensure that they will perform with unfailing speed, accuracy & consistent repeatability. Quiet electric motors drive the silent orbital movement of the tool holder. The same machine, using suitable tools can flare, flange, join & swage. Pressure for head forming is generated by either pneumatic or hydraulic power & is fully adjustable. Stepless adjustment of riveting force, time, stroke & speed allows the machine to perform on a wide variety of applications. |
| |
| Applications : |
| The spin riveting machine can be used for a range of jobs from freely swiveling joints to clamped, torque resisting joints. |
| |
 |
Rollers |
|
Bakelite-metal assembly |
|
Bicycle parts |
|
Chain assembly |
|
Fans |
|
Clutch /brake liners |
|
Toys |
|
Electronics/Electrical parts |
|
Castors |
|
|
Business machine |
|
Hand tools |
|
Automobile / Auto electricals |
|
Switch gear |
|
Surgical instruments |
|
Baggage |
|
Locks |
|
Typewriters |
| |
|
|
|
|
|
 |
|
| |
|
| |
|
| |
| Technical Specifications : |
| Models |
Riveting capacity
(M.S. 38 Kg/mm² U.T.S)
(mm) |
Throat depth
(mm) |
Shut height (Max)
(mm) |
Stroke Adjustable (mm) |
Cycle time Adjustable
(mm) |
Over all
dim.
(mm) |
Motor 3 Ø 415 V |
Air Pressure |
| Model - 003 |
3 |
110 |
200 |
0-30 |
0-9.9 Sec. |
470x400x860 |
0.25 HP (0.18 Kw) |
3-7 Kg/cm² |
| Model -005 |
6 |
110 |
180 |
0-30 |
0-9.9 Sec. |
470x400x860 |
0.5 HP (0.37 Kw) |
3-7 Kg / cm² |
| Model -008 |
8 |
140 |
225 |
0-45 |
0-9.9 Sec. |
570x525x1100 |
1 HP (0.75 Kw) |
3-7 Kg/cm² |
| Model -012 |
12 |
200 |
280 |
0-45 |
0-9.9 Sec. |
625x585x1325 |
1.5 HP(1.2 Kw) |
3-7 Kg/cm² |
| Model -016-H |
16 |
225 |
220 |
0-45 |
0-9.9 Sec. |
540x615x1375 |
6.0 HP (4.5 Kw) Including Power Pack |
0-80 Kg/cm² (Hydraulic Pressure) |
|
| |
| |
|
|
| Application in Automobile Industry: |
 |
|
 |
|
 |
|
 |
|
 |
|
 |
| Tie Rod Ball Joint Assly. |
Clutch Plate Assly. |
Horn |
Thermostat Housing Assly. |
Power Windows |
Gas Connector |
|
| |
| Application in Electrical Industry: |
 |
|
 |
|
 |
|
 |
|
 |
|
 |
| Electrical Contact |
Capacitor Cap |
Switch Gear Part |
Body of Harting Connector |
Capacitor Cap |
|
| |
| Application in Other Industry: |
 |
|
 |
|
 |
|
 |
|
 |
Bicycle Industry
Chain Sprocket |
Power Generator Industry
Cam Shaft |
Hand Tool Industry
Crimping Tool |
Domestic Appliance Industry
Motor Assly. of Washing Machine |
Gem / Jewellry Industry
Buffing / Polishing Brush |
|
| |
